määrittely
# | erä | Parametri | Huomautus | ||
1 | Nimelliskapasiteetti | 90AH | (25±2)°C, Standard Charge And Discharge | ||
2 | Typical Voltage | 3.2V | |||
3 | AC Impedance Resistance(1KHz) | ≤0,5mΩ | |||
4 | Standard Charge And Discharge | Charge/Discharge Current | 1C/1C | (25±2)°C | |
Cut Off Voltage Of Charge/Discharge | 3.65V/2.5V | ||||
5 | Maximum Charge/Discharge Current | Continuous Charge/Discharge | 1C/1C | According to continuous/ pulse charge and discharge ammeters | |
Pulse Charge/Discharge(30s) | 3C/3C | ||||
6 | Recommended Scope Of SOC | 10%~90% | N.A | ||
7 | Latauslämpötila | 0°C~55°C | According to continuous/ pulse charge and discharge ammeters | ||
8 | Purkautuva lämpötila | -20°C~55°C | |||
9 | Säilytyslämpötila | Short Term ( Within 1 month) | -20 ° C ~ 45 ° C: ssa |
N.A | |
Long Term ( Within 1 year) | 0 ° C ~ 35 ° C | ||||
10 | Storage Humidity Range | <95% | |||
11 | Self-discharge rate per month | ≤3%/month | Temperature: (25±2)°C,Storage Scope Of SOC: 30%~50%SOC | ||
12 |
Ulottuvuus | Leveys | 130.3±0.5mm |
Refer to Appendix ǀ | |
13 | Thickness( 30% SOC) | 36,7 ± 0,5 mm | |||
14 | High( Total) | 200,5 ± 0,5 mm | |||
15 | High( Subject) | 195,5 ± 0,5 mm | |||
16 | Tabs Distance | 67,0 ± 1,0 mm | |||
17 | Akun paino | 1994±50g |
Attentions
- It is necessary to ensure that the voltage, current and temperature of the cell are monitored and protected when the cell is charged and discharged.
- Please keep the cell away from heat source, fire source , strong acid, strong alkali and other corrosive environment.
- Do not short connect or install the battery with incorrect polarity at any time.
- Do not mix up with cells from different models or manufacturers.
- Do not use external force to make the cell fall, impact, puncture, do not disassemble the cell or change the external structure.
- Please keep the cell’s charge under 30% ~ 50%SOC, and avoid direct sunlight or high temperature and humidity environment when the battery is not used for a long time,
- Please wear protective devices such as rubber gloves when operating the battery.
Please immediately stop using if there have leakage, smoking or damage with cell , and contact our company to deal with.
hakemus
Tehtaamme
Pakkaus ja toimitus
The cells should be packed into boxes under the charge of 30% ~ 50%SOC. During the transportation, they should be protected from severe vibration, shock , extrusion, sun or rain.
varastointi
Cells should be stored (more than 1 month) indoor with a dry and clean environment at 0 ℃~35 ℃, and charged and discharged every 6 months. Keep the last charge under 30% ~ 50%SOC.
Ohje
Q1. Voinko saada näytetilauksen?
A. Kyllä, olemme tyytyväisiä näytteen tilaukseen testata ja tarkistaa laatu.
Q2. Entä läpimenoaika?
A. Näyte tarvitsee 3 päivää, massatuotantoaika tarvitsee 5–7 viikkoa, se riippuu tilauksen määrästä.
Q3. Onko sinulla mitään MOQ-rajaa?
V: Kyllä, meillä on MOQ massatuotannossa, se riippuu eri osanumeroista. 1 ~ 10kpl näytetilausta on saatavana. Matala MOQ, 1kpl näytteen tarkistamiseen on saatavana.
Q4. Kuinka lähetät tavarat ja kuinka kauan niiden saapuminen vie?
A. Saapuminen kestää yleensä 5–7 päivää. Lento- ja merikuljetukset ovat myös valinnaisia.
Q5. Kuinka jatkaa tilausta?
A. Ensin kerro meille vaatimuksesi tai sovelluksesi. Toiseksi tarjoamme vaatimusten tai ehdotustesi mukaan. Kolmanneksi asiakas vahvistaa näytteet ja asettaa talletuksen muodollista tilausta varten. Neljänneksi Järjestämme tuotannon.
Q6. Voinko logo tulostaa tuotteelle?
Kyllä. Ole hyvä ja ilmoita siitä meille virallisesti ennen tuotantoa ja vahvista ensin malli mallimme perusteella.
Q7.Mitä todistuksia sinulla on?
V: Meillä on CE / FCC / ROHS / UN38.3 / MSDS ... jne.
Q8.Mitä takuu?
V: 3 vuoden takuu
